Lock-core Type Security RJ45 Connector



In today's internet age, do you worry about your network cable being maliciously unplugged? COBTEL rj45 connector has solved this problem for you by developing a lock-core type security rj45 connector (patent number: ZL 201820243357.6), relieving your worries. Let me explain in detail:



1. Usage

★The lock-core type security ethernet connector is suitable for connecting and signal control of high-end computer rooms, high-definition monitoring, data centers, internet+, IoT, AI, hospitals, schools, public places 5G, and other equipment.



2. Product Design Advantages

★The lock-core type security ethernet connector is a high-tech product independently developed by our company with completely independent intellectual property rights (patent number: ZL 201820243357.6).

★The ethernet connector consists of three parts and can fully meet the FLUKE Cat6, and Cat6A single-unit test requirements with excellent network transmission performance.

★The lock-core type security ethernet connector is assembled with the sheath, lock core, and key to form a whole.

★The orifice of the sheath matches different specifications of outer wires and has strong interchangeability.

★Designed in the form of a lock core, when the key is inserted into the lock core and the slot above the sheath, the lock core is driven to tightly fit the ethernet connector's snap piece, achieving module locking and stable data transmission. When the key is withdrawn, the lock core is separated, causing the snap piece of the ethernet connector to press down and unplug from the network module, achieving the unlocking and network interruption functions. The key can then be easily removed.

3.  Standard Testing

★The patch cord is tested with a Fluke network tester and fully complies with TIA Patch Cord Cat6/Cat6A single unit, channel, and link test standards.

4. Product Compatibility

★The lock-core type security ethernet connector can be installed with network cables with an outer diameter of 5.0-6.5mm and core wire ID specifications of 0.85-1.10mm.

5.  Product Structure

★The lock-core type security ethernet connector is separated into the sheath, lock core, and key and is assembled, with reliable locking and unlocking. By driving the lock core forward and backward with the key, the network module can be locked and unlocked, with a compact structure and simple operation, and strong competitive advantages.

6. Excellent Materials

★The ethernet connector's gold sheet is made of C2680EH material with a coating specification of 100u" full-area nickel plating and 50u" thick gold plating on the contact surface, with low contact resistance and excellent transmission performance.

★The ethernet connector's body, sheath, lock core, etc., are all made of PC material, with a fire protection grade of UL 94V-0.
