Lockable Three-pin Female Power Cable Connector

Create robust, all-weather power cables with the SAC3FX female connector. Featuring a fast and secure locking system, an IP65 rating, and a 20A UL certification, it's the professional choice for reliable connections that never fail.

Send Inquiry

Add To Inquiry

Description

Product Features:

Lockable three-core female power cable connector with contacts for line, neutral and pre-adapted safety grounding
Used for electrical connection under outdoor conditions with protection grade IP65
Match with SAC3MX plug or SAC3MPX/SAC3MPX-LY socket
Fast and easy locking system with firm latch lock which does not fall off
High current capacity rated at 16A/250V AC TUV RH and 20A/300V AC UL
UL498 & UL50E Certification No. E356932
TUV RH(IEC60320-1) Certificate No.R 50660463 0001
Model: SAC3FX
Categories: Power Connectors, X Series IP65

Details

Electrical Parameters
Number of Contacts:2 + PE
Rated Current:16A TUV RH(20A UL)
Rated Voltage:250V AC TUV RH (300V AC UL)
Contact Resistance:≤ 3 mΩ
Dielectric Strength:4000V DC(1600V/min AC UL)
Insulation Resistance : > 1000 MΩ

Mechanical Parameters

Service life:> 1000 mating cycles
Cable Size :2.5 mm2(12AWG)
Cable OD:7-11 mm
Type of Terminals:Screw type terminals

Material and Environmental Parameters
Housing:PA
Contacts:Cu alloy
Contact surface:Ag
Protection degree:IP65
Flame retardant rating:UL94V-0
Temperature range:-30°C ~ +80°C
