OEM 110 Audio/Voice Patch Panel

1. Product Model: SMT-3009D-100P 2. Material Name: 100-pair patch panel 3. Specification Model: 1U 100-pair 110 patch panel 4. Series Description: As a voice series product in the comprehensive cabling system, the 110 patch panel plays a role in flexible signal transfer, flexible distribution,...

Send Inquiry

Add To Inquiry

Description

1. Product Model: SMT-3009D-100P

2. Material Name: 100-pair patch panel

3. Specification Model: 1U 100-pair 110 patch panel

4. Series Description: As a voice series product in the comprehensive cabling system, the 110 patch panel plays a role in flexible signal transfer, flexible distribution, and integrated unified management. The main characteristic of a comprehensive cabling system is the use of the same interface and transmission medium to transmit various types of information, which is achieved through jumper connections between different information patch panels.

5. Designed for 19-inch rack installation standards, sturdy, and easy to install, greatly improving work efficiency. Compatible with 19-inch equipment racks, cabinets, and wall mounts.

6. Performance is compliant with TIA/EIA/ISO standards.

7. Connection method: Supports enhanced 110 IDC termination.

8. Environmental requirements: Compliant with ROHS standards.

9. Material Introduction: The characteristic of a comprehensive cabling system is to use the same interface and transmission medium to transmit various types of information. By using jumper connections, the application functions of each desktop information point can be flexibly controlled. Therefore, for patch panels used to terminate horizontal twisted-pair cables from desktop information points, RJ45 interface patch panels should be used. For multi-pair voice cables from telephone equipment rooms, corresponding 110 patch panels can be used. Voice connectivity is achieved by jumpering between the 110 patch panel and RJ45 port.

10. Compatibility: Compatible for use with connectors of the same standard series.

11. Applicable Standards:

General Specification: YD/T 926.1-2009

Part Specification: YD/T 926.3-2009

12. Technical Parameters:

12.1 Electrical Characteristics:

Withstand Voltage: DC 1000V (AC 750V) for 1 minute without breakdown or arcing.

Insulation Resistance: Initial value ≥ 1000MΩ

12.2 Mechanical Characteristics:

IDC terminal accepts 23-26AWG twisted-pair cables.

12.3 Durability:

Wire Termination Cycles: 250 times

13. Materials and Surface Treatment:

Metal Material:

Bracket: Cold-rolled steel with powder coating

IDC wire terminal: Nickel-plated phosphor bronze

Non-metal Material:

Plastic: PC polycarbonate

14. Environmental Performance:

Temperature: -25 to +70°C

Humidity: ≤85% (Temperature of 85°C ± 3°C)

Salt Spray Test:

pH value of the salt solution before atomization: 6.5 to 7.2 (35±2°C)

A salt solution prepared using sodium chloride (analytical grade) and distilled or deionized water, with a concentration of (5±0.1)% (mass percentage)

Continuous atomization is recommended for 24 hours

During atomization, precautions should be taken to prevent the influence of oil, dust, and other impurities, as well as the temperature and humidity of the spraying air on the working space.
